Stripping Screening Recycled Asphalt Equipment

Mobile Phone

  • Type :BS
  • power:120-140 kW
  • Output:100-220 t/h
  • Diameter: 0-25mm

  • Product Details
  • High Lights
  • Technical Parameters
  • Related Cases
  • Related Products

Product Details

The recycling materials crushing method of Yalong is carried out in 2 stages. The primary crushing uses a single-roll type , similar to the milling drum, crushing the recycling materials to large pieces of diamond 0-70 mm . The secondary fine crushing is completed by two sets of crushing rollers, between which the space is adjustable according to different requirement during production.

The crusher of Yalong is specially designed for the crushing of asphalt recycling materials. The flexible crushing method makes the granulated structure close to natural structure, which can increase the addition ratio when recycling mixing.

High Lights

  1. Eco-friendly
  2. A better cost/performance ratio
  3. the recycling ratio of used asphalt materials
  4. Milling after sealing the used asphalt materials layer ,by controlling the recycling materials source ,to improve the proportion of additions.
  5. The structure of crushed particles is close to the original structure, increasing he addition ratio.

Technical Parameters

MODEL BS120A BS220A
OUTPUT 100-120t/h 180-220t/h
INSTALLATION POWER 120kW 140kW
SCREENING TYPE Single-screen Single-screen
FEEDING MATERIAL DIAMETER ≤50mm
PRODUCT DIAMETER 0-15mm

15-25mm

0-15mm

15-25mm

PRIMARY CRUSHING Single-roll crusher
SECONDARY CRUSHING Double-roll crusher
RECYCLING SILO CAPACITY 8m³
