1-Step Stabilized Soil Mixing Plant

Mobile Phone

  • Model: WBC300 ~ WBC1000
  • Capacity: 300 t/h ~ 1000 t/h
  • Cement Silo : 50 t ~ 200 t

Yalong Machinery is a professional manufacturer to produce stabilized soil mixing plant in China. Stabilized soil mixing plant is widely used to mixing different kinds of materials according to the requirements of customers.

100% Factory Supply

  • Product Details
  • High Lights
  • Technical Parameters
  • Related Cases
  • Related Products

Product Details

Programmable controller control, can realize manual, automati operation, simple operation, accurate measurement/reliable work.

Adopt high precision frequency conversion governor and computer automatic batching system to ensure the continuous measuring accuracy of materials. Material is measured by electronic belt scale, cement is measured by reducing scale, water is measured by frequency conversion, simple structure, stable and reliable work, easy adjustment and maintenance.

Can mix 4 ~ 6 kinds of different specifications, different varieties of materials (including cement), can configure a variety of proportions of cement stabilized soil, lime stabilized soil, cement treatment of roadbed materials.

The layout form of combined removable building block structure can be combined and configured according to the needs of users. It can adapt to different construction site conditions. All parts can be easily and quickly disassembled and loaded by truck.

High Lights

  1. Wide range of application, Producing many mixing materials such as cement. stabilized soil, lime stabillized soil, cement based material with different configuration ratio.
  2. Unlined Plate mixing technology and Cement Reduction Measuring  patent. technology, make the measuring accuracy and high-quality products.
  3. Switch the manual and automatic operation as will.
  4. Modular and automatic operation make it easy to install and disassemble quickly.
  5. Premium core components help to make high efficiency.
  6. It is easy to operate and maintenance. Eco-friendly and saving energy.


Technical Parameters

MODEL WBC300 WBC400 WBC500 WBC600 WBC800 WBC1000
OUTPUT 300t/h 400t/h 500t/h 600t/h 800t/h 1000t/h
INSTALLATION POWER 110kW 117.5kW 137kW 174.5kW 212kW 265kW
VOLUME OF COLD FEEDER 4*8m³ 4*8m³ 4*10m³ 5*10m³ 5*10m³ 6*13m³
BELT WIDTH 800mm 800mm 800mm 1000mm 1000mm 1200mm
MIXING POWER 55kW 55kW 2*37kW 2*45kW 2*55kW 2*75kW
POWDER TANK 50t 50t 100t 2*100t 2*100t 2*120t
FINISHED PRODUCT TANK 8.5m³ 8.5m³ 8.5m³ 8.5m³ 15m³ 15m³
TOTAL WEIGHT 35t 35t 38t 52t 54t 78t
MEASUREMENT METHODS variable speed measurement
