Bitumen Tank

Mobile Phone

Applications: Asphalt insulation, asphalt mixture containers
Asphal Flow Rate:32-100m³/h
Power: 350-1500kW
Capacity:10-44kW
Heat Supply:30-130*104kcal/h

Customized Bitumen Tank
The design layout of the concrete batching plant will be customized and built according to your project volume and equipment needs. Let's expect all the miracles to happen.

Inquire now for the latest quote!

Get A Free Quote Send Inquiry Now!

Product Description
Technical Parameter
Equipment Photo
Related Cases
Related Products

Product Description

Asphalt tank is a series of “internal heating type local rapid asphalt storage heater device”.

It is the most advanced asphalt equipment in China that integrates rapid heating, energy saving and environmental protection.
The direct heating mobile equipment in the product not only heats up quickly
Saves energy Fuel.
Does not pollute the environment.
The operation is simple and easy, the automatic preheating system completely eliminates the trouble of baking or cleaning asphalt and pipes.
The automatic circulation program makes the asphalt automatically enter the heater, dust collect

Directly heated

Directly heated

Technical Parameter

Thermal-oil heating bitumen tank

ASPHALT PLANT MODEL TO MATCH		1000/1200	1500/2000	2500/3000	4000
RATED THERMAL POWER (kW)		350	600	900	1500
HEAT SUPPLY (10⁴kcal/h)		30	50	75	130
THERMAL EFFICIENCY (%)		92	92	92	92
DESIGNED PRESSURE(MPa)		1.1	1.1	1.1	1.1
MAX.OPERATING TEMPERATURE (℃)		320	320	320	320
ASPHALT FLOW RATE (m³/h)		32	58	100	100
TANK VOLUME (m³)		0.3	0.6	0.7	0.95
MAIN PIPE DIAMETER (DN)		80	100	125	125
INSTALLED CAPACITY (kW)		10	15	28	44
APPLICABLE FUEL		Light oil, heavy oil, natural gas
FUEL CONSUMPTION (Nm³/h)		42	72	108	181
MAX. SHIPPING SIZE	LENGTH (m)	3.1	3.5	3.9	5.1
	WIDTH (m)	1.7	2.0	2.2	2.4
	HIGH(m)	1.6	1.9	2.1	2.4
